The gantry structure provides an extensive processing area for large sheets and heavy workpieces
A high-rigidity gantry structure and precision motion control ensure stability and accuracy across long cutting paths
Configurable for workpieces of different sizes, thicknesses and structures across a wide range of large-format applications
| Item | Description | |||
|---|---|---|---|---|
| Model | LM12030 | LM16030 | LM24030 | |
| Axis Travel | X-axis Travel | 12000 mm | 16050 mm | 24050 mm |
| Y-axis Travel | 3000 mm | 3020 mm | 3020 mm | |
| Speed | Max Idle Speed | 120 m/min | ||
| Max Acceleration | 0.6 - 1.0 g | |||
| Accuracy | Positioning Accuracy | ±0.05 mm | ||
| Repeat Positioning Accuracy | ±0.03 mm | |||
| Laser | Power | 12000 - 60000 W | ||
